The 50 new Lightplus trailers of the NOVUM generation are equipped with the new Kögel external frame profile and body as standard. This enables, for example, the lashing of the cargo in the VarioFix perforated steel external frame when there are aluminium lattices in the depot. The 13 pairs of lashing shackles, included as standard, have grip hooks at the sides for easier handling, and have a tensile force of 2,500 kilogrammes. For increased payload, the front wall, including the front volume corner posts, the rear corner posts and the rear wall door portal are made from aluminium as standard. As you would expect, the Kögel Lightplus trailers have the DIN EN 12642 Code XL load-securing certificate.
Kögel KTA trailer axle
The standard Kögel KTA trailer axles fitted on the Lightplus trailers are easy to maintain, whilst providing excellent tracking and reliability. The unique “double suspension” of the KTA, made from a soft rubber bearing and a spring steel wishbone, not only enhances the driving characteristics of the trailer but also reduces tyre wear.
A wide range of BTK customised equipment
To further reduce the weight of the trailers, BTK has opted for aluminium roof support frames and air tanks. A total of four rows of aluminium lattices, distributed over the post height, hold the load in place and protect the tarpaulin. The floor load-bearing capacity of the vehicle is increased to 7,200 kilograms with a reinforced frame. To withstand heavy daily use of the ramp, a 720-millimetre-long transition plate is mounted above the rear end beam, while for enhanced impact protection, the rear of the vehicle is equipped with protective rubber bumpers. The protective bumper is completed by an eight-millimetre-thick transverse steel angle over the entire width, and a locking cam protection in the middle of the frame end plate. Further customised equipment includes ADR certification complete with the corresponding equipment, an axle lift for the first axle, two pallet storage boxes, toolboxes and much more.
Cathodic dip-paint coating: lasting protection from corrosion
As with all Kögel vehicles for the forwarding industry, the entire vehicle frame on the Kögel Lightplus has long-term corrosion protection provided by nano cathodic dip-paint coating and subsequent painting.
